CABLE PROTECTORS

CROSS COUPLING & SPECIAL BESPOKE DESIGNS

Click the links below to find out more.

Land / Fixed Platform

Sub Sea

Ultra Deep Water

Bespoke Designs

Products

Land / Fixed Platform

CPL’s 1000 Series All Cast cable protectors are ideal for use on land rigs and offshore fixed platforms. They have cast steel bodies and collars, are extremely robust with field proven reliability. They are designed to withstand high impacts for lateral and axial loads while safely protecting the control lines and cables.

Typical specifications:-

•     gradual end chamfers to deflect protectors from hang up points

•     30 ton axial load rating

•     20 ton lateral load rating

•     pre-engaged captivated swing bolt fasteners

•     protect & support 100ft equivalent weight  of control line / cable

•     collars supported by cast body to protect bolts from shear stress

•     no loose components

•     all components comply with NACE Standard MR0175 for sour service

•     install in less than 30 seconds

•     re-useable

Back to Top

Sub Sea

Severe Service Cable Protectors

CPL’s Severe Service cable protectors are designed for use in subsea applications where hang up, severe dog legs and wear resistance are major concerns. They employ a more streamline design to eliminate the possibility of hang up and provide more resistance to wear under severe heave conditions.

Typical specifications:-

•     full and gradual end chamfers to deflect from hang up points

•     30 ton axial load rating

•     20 ton lateral load rating

•     pre-engaged captivated swing bolt fasteners

•     interlocking collar to protect bolts from fatigue under prolonged rig heave

•     protect & support 100ft equivalent weight  of control line / cable

•     no loose components

•     all components comply with NACE Standard MR0175 for sour service

•     install in less than 30 seconds

•     re-useable

Back to Top

Ultra Deep Water

Heavy Duty Cable Protectors

CPL’s Heavy Duty Cable Protectors are designed to withstand the highest lateral and axial load ratings of any cable protector. Over 60 ultra deep water wells have been completed in the last 3 years using CPL’s Heavy Duty cable protectors.

Typical specifications:-

•     full and gradual end chamfers to deflect from hang up points

•     70 ton axial load rating

•     70 ton lateral load rating

•     pre-engaged captivated swing bolt fasteners

•     protect & support 200ft equivalent weight  of control line / cable

•     interlocking cast bodies to protect bolts from fatigue during prolonged rig heave

•     no loose components

•     all components comply with NACE Standard MR0175 for sour service

•     install in less than 30 seconds

•     re-useable

Back to Top

Bespoke Protector Designs

CPL’s has extensive experience and expertise in designing and manufacturing bespoke design’s to meet  the criteria of each client’s application.

Our extensive list of special design’s include protectors for:

•     TRSV

•     GLM

•     CIM

•     CROSS OVER

•     LOW FRICTION FOR LONG REACH HORIZONTAL WELLS

•     CENTRALISING

•     DUAL STRING

•     ESP CENTRALISERS

•     MLE

•     ESP MLE NECK CLAMPS

•     COIL TUBING

•     SPLICE – SINGLE AND MULTIPLE

•     PERFORATION ALIGNMENT

•     UPPER ASV

•     MARINE RISER UMBILICAL CABLES

•     VIT

•     THERMAL INSULATION

•     TUBING HANGER

For all products – detailed specifications are available by contacting CPL.

Back to Top
